4V4.5ah Rechargeable AGM Battery for Emergency Lighting

• Overview
• Product Description
• Detailed Photos
• Certifications

Overview

Basic Info.

Model NO.	4V4.5Ah
Nominal Voltage	4V
Discharge Rate	Low Discharge Rate
Shape	Cylindrical Battery
Electrolyte	Acid
Installation	Packaged
Rechargeable	Chargeable
Color	Grey or Black or Orange
Terminal	F1/F2
Capacity	4.5ah@20hr-Rate to 1.75V Per Cell@25oc
Weight	0.48kg/1.058lbs
Size	L47.5*W47.5*H101(Th106)mm
Transport Package	20 PCS/CTN
Specification	CE, UL, RoHS, ISO 9001, ISO 14001, OHSAS 18001
Trademark	Long Way
Origin	China
HS Code	85072000
Production Capacity	500, 000 PCS/Month

Product Description

4V4.5ah Rechargeable AGM Battery for Emergency Lighting
LONGWAY® Standard battery is design for a general purpose by KaiYing Power.
2FM4.5 is a general purpose battery up to 5 years in float service ormore than 260
Cycles at 100% discharge in cycle service.As with all LONGWAY® Batteries, all are
rechargeable highly efficient, leak proof And maintenance free.

Specifications:

Package

Factory;

Applications:
² Alarm systems, Cable television, communications equipment, control equipment,
² Computers, electronic cash registers, electric test equipment,
² Electric powered bicycle and wheel chair,
² Emergency lighting systems, fire&security, geophysical equipment,
² Marine equipment, medical equipment,
² Micro processor based office machines, portable cine&video lights,
² Power tools, solar powered systems,
² Telecommunications systems, television&video recorders, toys,
² Uninterruptible power supplies, vending machines;

General Features
Ø Stable quality&high reliability Ø Sealed construction
Ø Environmentally friendly Ø Maintenance-free operation
Ø Low pressure venting system Ø Heavy duty grid
Ø Low self discharge Ø UL component recognition(MH46789)

For more information, please contact us and welcome you! ! Product Description Detailed Photos Certifications

Cells per Unit	2
Normal Voltage	4V
Capacity	4.5Ah@20Hr-rate to 1.75V per cell@25ºC
Weight	Approx. (0.48±3%)kg(1.058lbs)
Maximum Discharge Current	45A(5sec)
Internal Resistance	Approx. 22mΩ full charged @25ºC
Operating Temperature Range	Discharge: -20ºC~60ºC Charge: 0ºC~50ºC Storage: -20ºC~60ºC
Nominal Operating Temperature Range	25ºC±3ºC(77ºF±5ºF)
Float Charging Voltage	4.5~4.6VDC/unit Average @25ºC
Maximum Charging Current	1.35A
Equalization and Cycle Service	4.8V~5.0VDC/unit Average @ 25ºC(
Self Discharge	Self-discharge ratio less than 3%per month at 25ºC.
Terminal	F1(0.187)/F2(0.250)
Container Material	ABS(UL94-HB) *Flammability resistance of (UL94-V0) can be available upon request
